use lamp in luminaire with shield sign
TypeMandatory
StandardISO 7010 M070
Registered nameUse lamp in luminaire with shield
ComplianceCivil Defense requirements, KSA & UAE · OSHAD CoP 17.0
ColoursBlue / white
Size guide
Choose the size from the maximum distance the sign must be read from (ISO 3864-1 guidance).
SizeDimensionsViewing distance
A5148 × 210 mm1–3 m, Doors and small offices, viewing distance up to 3 m
A4210 × 297 mm3–5 m, Entrances and corridors, viewing distance up to 5 m
A3297 × 420 mm5–8 m, Halls and warehouses, viewing distance up to 8 m
Print tip: use card stock or mount on foam board/acrylic, and print the PDF at 100% (not “fit to page”).
This sign is also known as: use lamp in luminaire with shield sign، use lamp in luminaire with shield sign printable pdf، ISO 7010 M070 sign، use lamp in luminaire with shield sign Arabic English. Shape and colours follow ISO 7010 / ISO 3864-1, reference M070. The pictogram shown is illustrative and can be replaced with the official artwork.
