Back to Hazmat placardsHazmat
مادة سامة6.1مواد سامةToxic substanceMade free with Qalib · qalib.app

Previewing at A4 — 210×297 mm — Entrances and corridors, viewing distance up to 5 m

toxic substance placard

Class 6.1 covers toxic substances that cause harm or death by swallowing, inhalation or skin contact — cyanide, pesticides and arsenic and mercury compounds. The white diamond with the skull and crossbones means a small quantity can be enough to poison, and that the goods must be kept completely apart from food and animal feed.

TypeHazmat
Standard
ComplianceCivil Defense requirements — KSA & UAE · OSHAD CoP 17.0
Colours

Where is it used and when is it required?

Applied to drums, packages and containers, on the doors of chemical stores and agricultural pesticide depots, in warehouses in industrial cities, on trucks carrying dangerous goods, and in laboratories that keep toxic reagents in locked cabinets.

Regulation notes

GHS, the Globally Harmonized System of Classification and Labelling of Chemicals, is the classification system adopted across the Gulf, and the placard's colours, symbol and class number all derive from it. Placarding stores, containers and vehicles is the expected practice in Saudi and UAE industrial zones whenever dangerous goods are stored or moved.

  • The usual placard size on trucks and containers is 250 × 250 mm; a 100 × 100 mm label is enough on a drum or single package.
  • Print on a weatherproof, UV- and solvent-resistant material — pesticide stores are cleaned with chemicals.
  • Keep the class number "6.1" at the bottom corner clear: the skull symbol alone also appears on the 2.3 toxic gas placard.

Size guide

Choose the size from the maximum distance the sign must be read from (ISO 3864-1 guidance).

SizeDimensionsViewing distance
A5148 × 210 mm13 mDoors and small offices, viewing distance up to 3 m
A4210 × 297 mm35 mEntrances and corridors, viewing distance up to 5 m
A3297 × 420 mm58 mHalls and warehouses, viewing distance up to 8 m

Print tip: use card stock or mount on foam board/acrylic, and print the PDF at 100% (not “fit to page”).

This sign is also known as: toxic substance placard، class 6.1 hazmat placard pdf، poison store sign printable، pesticide dangerous goods label. Informational sign not governed by a mandatory standard; designed in one consistent style for everyday use.
