opaque eye protection must be worn sign
A mandatory (blue) sign requiring opaque, dark-lensed eye protection that blocks intense optical radiation — not clear safety spectacles. The solid blue circle with a white symbol is the ISO 7010 mandatory shape: an instruction to act, not a hazard warning, and M007 shows a face wearing solid shields against glare and ultraviolet radiation.
Where is it used and when is it required?
Required in arc welding bays and oxy-acetylene cutting areas in metalwork shops, at laser cutters and engravers in laboratories and fabrication shops, in UV curing rooms and water disinfection plant, and at melting furnaces and metal casting stations in factories.
Regulation notes
Civil Defense and occupational safety authorities in Saudi Arabia and the UAE expect welding and laser areas to be screened and marked with mandatory signage matched to the radiation level, as a condition of operating licences and hot-work permits. In the UAE, practice under the OSHAD Code of Practice 17.0 is for Arabic to sit above English on safety signs.
- Mount at the welding bay entrance or on the screening curtain at eye level (1.5–1.7 m), so it is read before the curtain is lifted.
- A4 on individual welding bays; A3 at the entrances to welding halls and laser rooms.
- State the required lens shade number in the organisation band under the sign — under-rated goggles give a sense of safety without the protection.
Size guide
Choose the size from the maximum distance the sign must be read from (ISO 3864-1 guidance).
Print tip: use card stock or mount on foam board/acrylic, and print the PDF at 100% (not “fit to page”).
This sign is also known as: opaque eye protection must be worn sign، welding goggles required sign printable pdf، ISO 7010 M007 sign، dark eye shields mandatory sign Arabic English. Shape and colours follow ISO 7010 / ISO 3864-1 — reference M007. The pictogram shown is illustrative and can be replaced with the official artwork.
